Detailed Product Description
A mobile phone signal repeater provides the ultimate solution in any area where cellular communications cannot work well due to leak of signals. The repeater device features easy installation & operation, build-in indoor antenna and no interference. It could also improve indoor electromagnetism environments, protract cellular battery life and reduce radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
Introduction to Mobile Phone Signal Repeater
l Enhance Mobile Phone Signal Strength
l Improve Communication Quality
l Reduce Cellphone Radiation
l Protract Cellular Battery Life
l Economic Building Cost
l Easy Operation
l Easy Installation
l Build-in Power Supply
The device featured by easy installation & operation and no interference. It is the ideal device for boost mobile phone signal. A mobile phone repeater could also improve indoor magnetism environments, protract cellular battery life and reduce radiation of cellphones.
Features
l High gain, easy installation and operation.
l Full-duplex, single-port design, build-in power supply.
l Use ALC technology, adjust extent automatically
l LED Light Working & Signal Condition Indicators
l Big linear power, control intermodulation & saturation stably
l Dependability stand by GB6993-86 standard
l Compatibility of electromagnetism according with ETS300 609-4
l CE and RoHs Approved
Technique
|
Frequency range
|
Uplink:1930~1990MHz
Downlink 2110~2180MHz
|
|
Gain ( dB)
|
Uplink Gp≥60 Downlink Gp≥65
|
|
Export power (Po)
|
≥20dBm
|
|
Pass band ripple
|
≤3dB
|
|
I/O impedance
|
50Ω/N connector
|
|
Noise figure
|
≤4dB
|
|
Transmission Delay
|
≤0.5μs
|
|
Ambient temperature
|
-10?/span>?/span>60?/span>
|
|
Power supply
|
AC110?/span>240V 45?/span>55Hz
|
|
Size
|
220 x180 x 20 mm
|
|
Reliability
|
To the GB6993-86 standard
|
|
Electromagnetic compatibility
|
To the ETS300 694-4 standard
|
|
Function
|
a) Power supply LED denote
b) Export power LED denote
|
|
coverage area
|
1000 m2
|
Installation Approaches
- Fix up outdoor antenna reception on housetop and point to signal tower.
- Connect outdoor antenna to “outdoor” port in repeater machine through cable.
- Connect indoor antenna(s) to “indoor” port in repeater machine through cable also.
- Plug power adaptor into AC power socket and finish installation.
Technique Supporting
- If still no signal receipt after activated repeater, please check if outdoor antenna point to signal tower or elsewhere have strong signal and check if strength achieve -70DBM.
- If cannot call out, please adjust the direction of outdoor antenna.
- If strength is not steady, please check if outdoor & indoor antennas are too close. Please ensure the outdoor and indoor antennas have distance of 20
Accessories
Selection Outdoor antenna use 7 unit yagi type antenna, indoor antenna use board or rooftop antenna and signal wire use coaxial-cable.
Packing list
Main unit 1pc
Power supply 1pc
User manual 1pc
SpecificationsInstallation Sketch Map
